Product information
1. Overview of SOLID EDGE software:
Solid Edge software has been developed by Siemens since 1996 and is currently available in most countries around the world. It is a complete CAD/CAM/CNC software system that uses synchronous technology to help engineers increase productivity. Design faster, edit faster, and reuse data better.
Solid Edge software offers a variety of applications to meet the diverse needs of designers: from powerful 2D drawing design to advanced 3D design tools, perfect for assembly design, rendering Automated drawing, assembly and simulation.
Solid Edge is Siemens' most comprehensive open digital product development system that delivers design and manufacturing benefits.
2. Outstanding features of the SIEMENS SOLID EDGE module
Key features of Solid Edge include:
- 3D design
- Surface design
- Sheet metal design
- Free surface design "Freedom"
- Frame design and welding
- Assembly drawing
- Export production drawings
- Synchronous technology
- Directly open files from other 3D software
- Standard parts library
- Motion simulation
- 3D printing service
- Cloud data connection (Cloud)
*CAM machining: Solid Edge integrated with CAM Pro (NX CAM) is an expansion module of NX CAM that provides machining solutions from 3 to 5 axes, wire cutting machining, turning machining,... when using CAM The interface will be completely NX CAM. When modifying the design on Solid Edge, it will automatically update and synchronize data to CAM without having to reprogram from scratch, helping to optimize and save more time.
3. Application of SIEMENS SOLID EDGE
With current global trends and international integration, choosing a solution that suits job requirements as well as compliance with industry regulations and national laws requires businesses to innovate and have the right investment orientation in copyrighted CAD/CAM/CNC software solutions.
Siemens' Solid Edge software solution is a solution that fully meets the above factors and is suitable for small and medium enterprises, businesses that only need to invest at a low cost but get benefits. Comprehensive and synchronized solution on a single software system.
Solid Edge software provides the most intuitive and efficient design and analysis portfolio that enables accelerated product development for consumer goods including 3D design, visualization, simulation, prototyping, manufacturing and design project management. Electromechanical assembly design is also accelerated with integrated wiring and PCB design capabilities (from Mentor graphic).
