1. What is a Multitask processing machine?
Multitask machining machines are machining machines that can perform many machining functions (turning, milling, drilling, tapping, ...), multi-axis machining functions, providing the most modern machining solutions today. Multitask will bring the ability to machine highly complex parts by combining the movement of the machine table with the cutting tool.
Multitask has revolutionized manufacturing and plays an important role in today's smart factories.
For Multitask machining machines, there will usually be 8 machining axes: X1, Y1, Z1, X2, Z2, B, C1, C2. With 8 machining axes, this machine can process all current products in one set.
Benefits of Multitask processing machines:
- Improve machining accuracy
- Improve machining capabilities, production capacity, flexibility, and automation
- Reduce operating labor costs
- Significantly reduce production time and costs
- Reduced factory area due to multiple functions
2. The power of NX CAM in Multitask machining
NX CAM software has full machining programming functions for Multitask machines: milling from 3 to 5 axes, turning, synchronizing the movement of spindles and tool stations, simulating machining machines, exporting post processors.
Combined milling and turning:
Programming tools for 3 - 5 axis milling and turning in NX CAM effectively support the construction of machining programs.
C-axis machining:
Easily switch C-axis machining features, support quick cutting and G-Code export.
In addition, some advanced machining functions in the Mutitask machine are also very important such as: balancing turning, parallel machining of 2 spindles, transferring workpieces between spindles,... are also easily built into NX CAM software. by using additional UDE functions
Synchronization of machining – Synchronization:
Machining assimilation helps manage the order of machining programs according to different timelines. Synchronization helps avoid machining collisions and optimize machining time.
Multitask machining simulation:
Nowadays, Multitask machining simulation is extremely necessary for complex multi-axis machining machines. It helps check machining residuals and control machining collisions that may occur. Machine simulation is also easy to build to suit many different types of machines and controllers.
In addition, the library of post processors - Post Hub with 1,500 different post processors also effectively supports the current processing process of businesses.
